Fluke 750R30 Reference Pressure Module

The Fluke 750R30 Reference Pressure Module is suitable for permitting differential, gage, and absolute pressure measurements when used in conjunction with Fluke 750 and 740 Series DPCs or 725, 726 MPCs. This module has 0 to 5000 psi parameter/range, 3X burst rating, 316 SS Hi Side Media, ± 0.01% of FS reference uncertainty, and the capability to show the pressure in a maximum of 11 varying engineering units. There is also a one-meter cable between the pressure module and calibrator. This helps minimize the span of tube linked to the pressure foundation. In addition, the remote pressure head offers further security and expediency, since it eliminates the calibrator and user from the pressure foundation for semi-remote measurements.

One of the most beneficial features of the Fluke 750R30 Pressure Module is the digital communication, which eradicates mistakes typically caused by poor linking and electrical intrusions. The Pressure Modules in the 750x Series can be swapped since every measurement is finished in the pressure module, then transferred to the calibrator in a digitized method. The Pressure Modules are calibrated separately from the calibrator. The Fluke 750R30 Reference Pressure Module is also categorized with a label for pressure range and media compatibility.

If the Fluke 750R30 module is utilized with a 750 Series Documenting Process Calibrator, then pressure estimations can be date/time stamped. Pressure estimations can also be saved by electronic means for viewing in the future. These capabilities eradicate mistakes, save valuable time, and comply with quality requirements and guidelines.
